The fluorine-lined three-way ball valve has a compact structure, beautiful appearance, and good sealing performance. It can switch the flow direction of the medium in the pipeline, and can also connect or close two perpendicular channels. The four-seat sealed pneumatic three-way ball valve has beautiful appearance and compact and reasonable structure; it can not only switch the flow direction of the medium, but also connect the three channels to each other. Now it can also close any channel and connect the other two channels, flexibly control the confluence or diversion of the medium in the pipeline, and is widely used in the control of highly corrosive media such as acids and alkalis and toxic, volatile, and permeable gas and liquid media.
Features:
- Corrosiveness: It can resist corrosion from almost all media (including concentrated nitric acid and aqua regia).
- Large flow capacity and unrestricted flow direction of the medium.
- Good sealing performance and small leakage; the sealing valve seat is made of polytetrafluoroethylene, which has reliable sealing and self-lubricating properties and low leakage.
- In addition to general gas and liquid, it is more suitable for high viscosity and medium with fibrous and suspended soft particles.
- Simple structure and easy maintenance.
- The gear rack pneumatic actuator with multiple springs and the angular stroke electric actuator are convenient for various environments and are currently the most widely used control and cut-off system.
Lining material: FEP, PFA, GXPO, etc.
Drive mode: manual, worm gear, electric, pneumatic, hydraulic.
